Read here about our light carpet design example and demo for automotive side mirrors and architectural illumination. Created in a single iteration using PlanOpSim’s MetaCell and MetaComponent and a PDK.
These same design techniques are used for designing dot projectors and other structured light applications, such as automotive headlamps and LiDAR optics.
Technical highlights
- Designed in < 8 hours using MetaCell, MetaComponent, and Moxtek’s built-in 532nm PDK.
- 80% efficiency and 0.3% zero-order (ZO) leakage, ZO deliberately angled into beam-block
